STL57N65M5
N-Channel 650 V 4.3A (Ta), 22.5A (Tc) 2.8W (Ta), 189W (Tc) Surface Mount PowerFlat™ (8x8) HV
Availability: In Stock
Package Type: POWERVDFN-8
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the STL57N65M5 by STMicroelectronics and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the STL57N65M5
| Part Name | STL57N65M5 |
| Manufacturer | STMicroelectronics |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Drain Source Voltage (V) | 710 V |
| Typical Gate Charge @ Vgs | 96 nC @ 10 V |
| Channel Mode | Enhancement |
| Maximum Continuous Drain Current (A) | 22 A |
| Maximum Power Dissipation | 2.8 W |
| Series | MDmesh M5 |
| Channel Type | N |
| Maximum Gate Source Voltage (V) | -25 V, +25 V |
| Length | 8 (mm) |
| Transistor Material | Si |
| Width | 8 (mm) |
| Maximum Gate Threshold Voltage (V) | 5 (V) |
| Package Type | PowerFLAT 8 x 8 HV |
| Number Of Elements Per Chip | 1 |
| Pin Count | 5 |
| Minimum Gate Threshold Voltage (V) | 3 (V) |
| Mounting Type | Surface Mount |
| Height | 0.95 (mm) |
| Maximum Operating Temperature | +150 °C |
| Maximum Drain Source Resistance | 69 mΩ |
| Transistor Configuration | Single |
