TLV320AIC3104IRHBT
Low-Power Stereo CODEC with 6 Inputs, 6 Outputs, HP Amp and Enhanced Digital Effects
Availability: In Stock
Package Type: VQFN-32-32
CAD Models: Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the TLV320AIC3104IRHBT by Texas Instruments and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
The 2D model for this
part is not available.
The Exact Symbol for this part is not available.
BuildFootprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the TLV320AIC3104IRHBT
| Part Name | TLV320AIC3104IRHBT |
| Manufacturer | Texas Instruments |
| MOQ | 1 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Pin Count | 32 |
| Number Of Adcs | 2 |
| Number Of Dacs | 2 |
| Dimensions | 5 x 5 x 0.9 (mm) |
| Mounting Type | Surface Mount |
| Power Supply Type | Single |
| Adc Dac Resolution | 24 (bit) |
| Number Of Adc Inputs | 3 |
| Typical Operating Supply Voltage (V) | 1.8 V, 3.3 V |
| Package Type | QFN |
| Interface Type | Serial-I2C |
| Minimum Operating Temperature | -40 °C |
| Ic Type | Audio Codec IC |
| Number Of Channels | 2 |
| Sampling Rate | 96 (ksps) |
| Maximum Operating Temperature | +85 °C |
| Number Of Dac Outputs | 6 |
