XD5PA12
IP66 Joystick Switch; 2 axes;3Pos;1NO | Schneider Electric XD5PA12
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the XD5PA12 by Schneider Electric and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the XD5PA12
| Part Name | XD5PA12 |
| Manufacturer | Schneider Electric |
| Category | Switches |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Better World Verification | Green Premium |
| Better World Product | Yes |
| Ip Rating | IP66 |
| Contact Current Rating (A) | 220 mV |
| Series | Harmony XB5 |
| Contact Configuration | SPST |
| Number Of Axes | 2 |
| Contact Voltage Rating (V) | 600 (V) |
| Handle Type | Lever |
