ZB4BG4
Switch, 22mm, KEY OPERATOR, 2 Position, MAINT./MAINT., KEY REMOVAL POS. 1, 2 | Schneider Electric ZB4BG4
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the ZB4BG4 by Schneider Electric and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the ZB4BG4
| Part Name | ZB4BG4 |
| Manufacturer | Schneider Electric |
| Category | Switches |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Better World Verification | Green Premium |
| Better World Product | Yes |
| Number Of Keys | 2 |
| Illuminated | No |
| Ip Rating | IP66, IP67, IP69(IP69K) |
| Series | ZB4 |
| Angle Of Throw | 90 (°) |
| Switch Actuation | Latching |
| Key Type | 455 |
| Minimum Operating Temperature | -40 (°C) |
| Distrelec Product Id | 13512282 |
| Cutout Diameter | 22 (mm) |
| Number Of Positions | 2 |
| Maximum Operating Temperature | +70 (°C) |
| Mechanical Life | 1000000 |
